Advantage Air ADM 240 Volt Drive Open/Closed, Actuator On/Off Black Zone Motor

Description

For sale is an Advantage Air ADM 240 Volt Drive Open/Closed, Actuator On/Off Black Zone Motor in new condition.

DISCLAIMER: It is highly recommended to use a licensed electrician for the installation of the 240V Damper motor due to its high voltage of 240 volt!



FEATURES

• 240 volt A/C drive open/ drive close motors
• 15 second drive time
• Drive return
• Motor switches off when not driving saving energy and running costs
• External indicator shows a damper position
• Low profile enables the damper to fit in tight spaces
• Colour coded for easy identification (240V motor has a black lid)
• Tough external casing
• Suitable for advantage air exact airboxes
• Connects with the following systems

          * Brivis Heaters

          * Heating and Cooling

          * Gas Heaters



CONSTRUCTION

• Body and lid is injection moulded from blended engineering plastic.



APPLICATIONS

• The Sonic-Drive damper actuator is a 240V AC drive open drive close damper actuator.
• Used to control air flow in low-pressure air conditioning ducts.
• This product is designed specifically to be used on Advantage Air’s range of Exact Air Regulators and is pre-installed onto the Exact Air Regulator damper.
• Suitable for all domestic and commercial two-position (open, closed) applications under 2.5 Nm.
• Suitable for all Exact Air Regulators and Advantage Air barrel dampers 150 dia to 550.



SPECIFICATION

• ELECTRICAL RATING: 240 VAC 50 Hz 0.03 A.
• TORQUE: 2.5Nm.
• ACTUATOR CYCLE TIME: 16s (from fully open to fully closed).



WARNING !

DO NOT CONNECT ANY OTHER MOTOR OR DEVICES ONTO THE SAME SWITCH!

DO NOT ATTEMPT TO SIMULATE OPERATION OF THE DAMPER ACTUATOR BY ROTATING THE CONNECTION COUPLING AND/OR DAMPER BLADES.

ABUSE OF THIS NATURE CAN RESULT IN PERMANENT DAMAGE TO THE DAMPER ACTUATOR.



We also stock other types of Zone motors in the Advantage Air range.

• Advantage Air Temperature Control Zone Motor Clip-In 24 Volt Damper Motor

• Advantage Air ELV 24V Yellow Zone Motor
• Used Advantage Air ADM24GreenP Zone Motor
• Used Advantage Air ADM24S Red Zone Motor



Please note: The pictures of this item are for reference purposes only as many of the parts we have in stock. Items may vary like marks, boxes, colour and more.

If you would like to see a picture of a part you wish to order, please contact our office for this.

Please check out our YouTube Channel for installation/set-up and other helpful tips and guides.

At Controlled Climate Hub, we can both supply and provide support with  the  set -up  and installation of all parts that are supplied.

Please feel free to send us a message or contact us at 0404854822. Our team aim to respond to all messages promptly.



NOTE: As our products are listed on another platform, we may need to cancel an order if the item sells on that platform. We will notify you immediately and do our best to provide a comparable alternative.
